specification |
---|
colour | Matt Olive with Black Gold | cassette | sram pg-1230 eagle, 11-50, 12 speed |
frame | carbon, uni-directional multi monocoque front triangle with internal cable routing, tapered head tube, iscg, 2 bolt guide mounts, alloy symmetrical scr rear triangle, shape.It and 148mm boost dropouts | chain | sram GX eagle, 12 speed |
fork | rockshox pike select rc 27.5", 140mm travel, 37mm offset, debonair, charger rc damper, fast black coating, tapered steerer, 110mm x 15mm boost, maxle ultimate | crankset | sram x1 eagle, x-sync 2, direct mount 32t, dub, 170mm, boost, 12 speed |
rear shock | rockshox deluxe select + rt, debonair, fast black coating, adjustable rebound and 2 position compression | bottom bracket | sram dub, bsa, 73mm |
headset | fsa no. 42 orbit zs plus, integrated, 1 1/2" lower and 1 1/8" upper sealed cartridge bearings | seatpost | whyte drop.It ii adjust, 30.9mm, s/m 120-150mm travel, l/xl 140-170mm travel, paddle remote lever |
rear hub | alloy, double sealed cartridge bearings, 12mm x 148mm boost thru axle, 32 hole | saddle | whyte custom, dual density, triple panel design |
front hub | alloy, double sealed cartridge bearings, 15mm x 110mm boost thru axle, 31mm torque caps, 32 hole | handlebar | whyte 6061 alloy, 31.8mm, s 15mm rise, 760mm wide, m/l/xl, 30mm rise 780mm wide |
spokes | dt swiss champion 2.0mm, black stainless, brass nipples | stem | whyte gravity stem, 35mm extension |
rims | wtb st i30 tcs 2.0 system, pinned joint, tubeless ready, 32 hole | grips | whyte lock-on enduro grip |
tyre | maxxis minion dhf tr 27.5" x 2.6" 120tpi, exo sidewall protection, 3c maxx terra, front, maxxis dissector tr 27.5" x 2.6" 60tpi, exo+ sidewall protection, rear | brakes front | sram guide g2 r, 4 piston, 180mm disc |
shift levers | sram GX eagle, mmx clamp, 12 speed | brakes rear | sram guide g2 r, 4 piston, 180mm disc, internal routing |
front mech | n/a | brake levers | sram guide g2 r, matchmaker |
rear mech | sram GX eagle, 12 speed | pedals | none |
weight | tbc | | |
