Frame | Raze 29 Stealth Air full Carbon, Zero Suspension System, 130mm travel, Forward Geometry, Carbon Monoblock upper link, Boost 12×148mm rear axle, tapered head tube, 73mmBSAbottom bracket, dedicated 1x drivetrain design,HHGinternal cable routing, EnduroMAXsealed bearings, shock mudguard,ISCG05, custom frame protectors. |
Rear Shock | Fox Float Factory KashimaEVOL, 205×57.5mm. Settings: 2-position compression (Open/Firm), rebound, air preload. Trunnion top mount, 30×8mm bottom bushings |
Shock Settings | Light compression, light rebound, air volume spacer 0.6 |
Fork | Fox 36 29 Float GRIP2 Factory Kashima, 150mm, tapered steerer tube, Boost 15×110mm axle, 44mm offset. Settings: high and low-speed compression, high and low-speed rebound, air preload |
Headset | Acros custom for 1-1/2” head tube, angular contact bearings 40×52×7, Internal cable routing |
Stem | Onoff Krypton FG 30mm,CNC, 31.8mm barbore |
Handlebar | Onoff Krypton Carbon 1.0, rise: 25mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore |
Grips | Onoff Desert, 1lock-on, 135mm |
Seatpost | Fox Transfer Factory Kashima internal, diameter 31.6mm, S size: 363.5×125mm, M size: 418.3×150mm, L size: 475.1×175mm, XL size size: 475.1×200mm |
Saddle | Fizik Vento Argo X5 |
Front Brake | Sram Level Bronze Stealth, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steelbacked organic pads |
Rear Brake | Sram Level Bronze Stealth, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steelbacked organic pads |
Rims | Mavic CrossMax Carbon XL R, 29 Boost 30mm internal width, hookless, tubeless ready, 24 spokes |
Spokes | 24 straight-pull double butted spokes |
Front Hub | Infinity hub, Boost 15×110mm, IS 6 bolts |
Rear Hub | Infinity hub, ID360 freewheel technology, Boost 12×148mm, IS 6 bolts |
Front Tyre | Maxxis Dissector 29×2.4 WT, tubeless ready, 3CMAXXTERRAcompound,EXO+ protection, 120TPI, folding bead |
Rear Tyre | Maxxis Aggressor 29×2.3, tubeless ready, dual compound, Exo protection, 60TPI, folding bead |
Crankset | Sram XX Carbon Eagle T-Type, Boost,DUBaxle, Direct mount chain ring, S size: 170mm M size: 175mm L size: 175mm XL size: 175mm, CL55 |
Chainring | 32T,CNC-machined alloy, T-Type |
Bottom Bracket | SramDUBBSA, sealed bearings, 73mm |
Chain | Sram X0 Eagle T-Type, 12s, Powerlock |
Rear Derailleur | Sram XX EagleAXS, T-Type roller bearing clutch, cage lock, long carbon cage, 1×12s |
Shifter | Sram EagleAXSPodMMX, 12s |
Cassette | Sram XS-1295, 10-52T, T-Type, 12s |
Max System Weight | 120kg – The maximum system weight is the maximum total weight of the bike, rider and any luggage combined |
