Frame | Raze 29 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 130mm travel, Forward Geometry, one piece Monoblock upper link, Boost 12×148mm rear axle, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, telescopic seatpost internal routing, MAX capacity sealed bearings, ISCG 05 |
Rear Shock | Fox Float EVOL Performance, 205×57.5mm. Settings: 2-position compression adjustment (Open/Firm), rebound, air preload. Trunnion top mount, 25×8mm bottom bushings |
Shock Settings | Light compression, light rebound, air volume spacer 0.6 |
Fork | RockShox 35 Gold 29 RL, 150mm, Solo Air, tapered steerer tube, Boost 15×110mm axle, 35mm steel stanchions, 44mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload |
Headset | Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41×30.2×7×45°x45°, bottom 51.9×40×8×45°x45° |
Stem | Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore |
Handlebar | Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore |
Grips | Onoff Twin, 1lock-on, 135mm |
Seatpost | Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 405×95-125mm, |
Saddle | MDK series PU 2023 |
Front Brake | Sram Level T, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad |
Rear Brake | Sram Level T, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad |
Rims | Mavic CrossRide 29 Boost, 30mm internal width, tubeless ready, 28 spokes |
Spokes | Mavic 28 round j-bend stainless steel |
Front Hub | Mavic Boost 15×110mm, sealed bearings, IS 6 bolts |
Rear Hub | Mavic ID360 freewheel technology, Boost 12×148mm, IS 6 bolts, HG freehub |
Front Tyre | Maxxis Dissector 29×2.4 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead |
Rear Tyre | Maxxis Aggressor 29×2.3, tubeless ready, dual compound, Exo protection, 60TPI, folding bead |
Crankset | Sram SX Eagle, Boost, DUB axle, Direct Mount chain ring, S/M size: 170mm, L/XL size: 175mm |
Chainring | 32T, steel, X-Sync 2 |
Bottom Bracket | Sram DUB BSA, sealed bearings, 73mm |
Chain | Sram SX Eagle, 12s, Powerlock |
Rear Derailleur | Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1×12s, X-actuation 1:1 |
Shifter | Sram Trigger SX Eagle, 12s, X-Actuation 1:1 |
Cassette | Sram PG-1210, 11-50T, 12s |
Derailleur Hanger | Sram UDH |
Max System Weight | 120kg – The maximum system weight is the maximum total weight of the bike, rider and any luggage combined |
