Fork | Fox 32 Step Cast Float FIT4 EVOL Factory Kashima, 100mm, tapered steerer tube,15×110mm Boost axle, remote lockout, offset 44mm. Settings: lockout, compression micro-adjustment at low-speed, rebound, air preload |
Headset | Onoff Titan tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41.8×30.5×8×45ºx45º, bottom 51.9×40×8×45ºx45º |
Fork Remote | Fox single pull |
Stem | MDK, 6061 T6 Alloy, 31.8mm barbore, rise: +/-5º, length: sizes S/M: 60mm, size L: 70mm, size XL: 80mm |
Handlebar | Onoff Helium Carbon 0.2, rise: 4.8mm, width: 760mm, 9º backsweep, 0º upsweep, 31.8mm barbore |
Grips | Onoff Desert, 1lock-on, 135mm |
Seatpost | Onoff Helium Carbon 0-R VFLEX, diameter 27.2mm, length 400mm |
Saddle | Fizik Antares R7 |
Front Brake | SRAM Level TLM, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad |
Rear Brake | SRAM Level TLM, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad |
Rims | Mavic Crossmax Carbon SL R 29, 26mm internal width, hookless, tubeless ready, 24 spokes |
Spokes | Mavic straightpull duble butted, contactless lacing |
Front Hub | Mavic, Boost 15×110mm, IS 6 bolts |
Rear Hub | Mavic, Boost 12×148mm, ID360 Ratched system, IS 6 bolts, XD freehub |
Front Tyre | Maxxis Rekon Race 29×2.35, EXO protection, tubeless ready, 120TPI, folding bead |
Rear Tyre | Maxxis Rekon Race 29×2.35, EXO protection, tubeless ready, 120TPI, folding bead |
Crankset | Truvativ Stylo Carbon Eagle, 12s, Boost, DUB axle, Direct Mount chain ring, S size: 170mm, M/L/XL size: 175mm |
Chainring | 34T, steel, X-Sync 2 |
Bottom Bracket | SRAM DUB BSA, sealed bearings, 73mm |
Chain | SRAM SX Eagle, 12s, Powerlock |
Rear Derrailleur | SRAM X01 Eagle, Type 3 roller bearing clutch, cage lock, 1×12s, X-Actuation 1:1 |
Shifter | SRAM Trigger GX Eagle, 12s, X-Actuation 1:1 |
Cassette | SRAM XG-1275, 10-50T, 12s |
Derailleur Hanger | SRAM UDH |
Max System Weight | 120kg – The maximum system weight is the maximum total weight of the bike, rider and any luggage combined |
