FRAME | Foxy 29 stealth air full carbon, zero suspension system, 150mm travel, forward geometry, carbon monoblock upper link, boost 12x148mm rear axle, tapered head tube, 73mm bsa bottom bracket, dedicated 1x drivetrain design, hhg internal cable routing |
FORK | Öhlins rxf 36 m.2 29, 160mm, ttx18 twin tube cartridge, tapered steerer tube, boost 15x110mm axle, offset 44mm. settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload, ramp chamber. fork settings: c20 r40 |
REAR SHOCK | Öhlins ttx air 205x65mm. settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload. trunnion top mount, 30x8mm bottom bushings |
HEADSET | Acros custom for 1-1/2" head tube, angular contact bearings 40x52x7, internal cable routing |
STEM | Onoff sulfur fg 30mm, 6061 forged alloy, 31.8mm barbore |
BARS | Onoff sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore |
FRONT BRAKE | Sram code r, oversized 4-piston caliper, centerline 200mm is 6 bolts one-piece rotor, steel-backed metal sintered pads |
REAR BRAKE | Sram code r, oversized 4-piston caliper, centerline 180mm is 6 bolts one-piece rotor, steel-backed metal sintered pads |
BRAKE LEVER | Sram code r, tool-free reach adjust |
REAR MECH | Sram gx eagle, type 3 roller bearing clutch, cage lock, 1x12s, x-actuation 1:1 |
SHIFTERS | Sram trigger gx eagle, 12s, x-actuation 1:1 |
SPEED | 12 |
RIMS | E*thirteen lg1 plus enduro, iw30 hookless, 6069 welded aluminum, 30mm internal width, tubeless ready, 28 spokes |
FRONT HUB | E*thirteen boost 15x110mm, triple-sealed, fully machined aluminum, is 6 bolts |
REAR HUB | E*thirteen boost 12x148mm, triple-sealed, fully machined aluminum w/6-degree engagement, is 6 bolts, xd freehub |
SPOKES | E*thirteen custom hive triple-butted black steel, alloy nipples, nipple washers |
FRONT TYRE | Maxxis minion dhf 29x2.5 wt, tubeless ready, 3c maxx terra compound, exo+ protection, 120tpi, folding bead |
REAR TYRE | Maxxis minion dhr ii 29x2.4 wt, tubeless ready, 3c maxx terra compound, exo+ protection, 120tpi, folding bead |
SEAT POST | Onoff pija dropper internal, diameter 31.6mm, s size: 405x95-125mm, m size 458x120-150mm, l size: 498x140-170mm, xl size: 498x140-170mm |
SADDLE | Sdg bel-air 3.0, lpu foam, steel rails |
CHAINSET | Sram gx eagle, boost, dub axle, direct mount chain ring, s/m size: 170mm, l/xl size: 175mm |
BOTTOM BRACKET | Sram dub bsa, sealed bearings, 73mm |
CHAIN | Sram nx eagle, 12s, powerlock |
CASSETTE | Sram xg-1275, 10-52t, 12s |
PEDALS | Resin platform |
