Frame | F-Podium 29 Stealth Air Full Carbon,XCOOptimized Zero Suspension System, 110mm, XC Forward Geometry, Carbon Monoblock upper link,BSAbottom bracket, tapered head tube,HHGinternal cable routing, dedicated 1X drivetrain design, Boost 12×148mm rear axle, shock mudguard, postmount rear brake mount. |
Rear Shock | Fox Float SL Performance SVEVOL, 165×45mm. Settings: 3 position remote compression (open/medium/lock), low-speed rebound, air preload. Trunnion top mount, 30×8mm bottom bushings |
Shock Settings | Medium compression, medium rebound, Lockout 430, 1 Token |
Fork | Fox 34 Step Cast Float GripEVOLPerformance, 120mm, tapered steerer tube,15×110mm Boost Kabolt axle, offset 44mm. Settings: remote 3pos Push to lock, rebound, air preload |
Fork Remote | Fox 3 position dual pull push to lock |
Headset | Acros custom for 1-1/2” head tube, angular contact bearings 40×52×7, Internal cable routing |
Stem | MDK, 6061 T6 Alloy, 31.8mm barbore, rise: +/-5º, length: S size: 50mm, M size: 50mm, L size: 60mm, XL size: 70mm |
Handlebar | Onoff Helium Carbon 0.2, rise: 4.8mm, width: 760mm, 9º backsweep, 0º upsweep, 31.8mm barbore |
Grips | Onoff Desert, 1lock-on, 135mm |
Seatpost | Onoff Pija dropper internal, diameter 31.6mm, Universal lever, S size: 405×95-125mm, M size: 458×120-150mm, L size: 498×140-170mm, XL size: 498×140-170mm |
Saddle | Fizik Vento Argo X5 |
Front Brake | Sram Level Bronze 2P Stealth, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad |
Rear Brake | Sram Level Bronze 2P Stealth, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad |
Rims | Mavic CrossMax Carbon XL R, 29 Boost 30mm internal width, hookless, tubeless ready, 24 spokes |
Spokes | Mavic 24 straight-pull double butted spokes |
Front Hub | Mavic Infinity hub, Boost 15×110mm, IS 6 bolts |
Rear Hub | Mavic Infinity hub, ID360 freewheel technology, Boost 12×148mm, IS 6 bolts, XD freehub |
Front Tyre | Maxxis Rekon Race 29×2.35,EXOprotection, tubeless ready, 120TPI, folding bead |
Rear Tyre | Maxxis Rekon Race 29×2.35,EXOprotection, tubeless ready, 120TPI, folding bead |
Crankset | Sram X1 Carbon Eagle, Boost,DUBaxle, Direct mount chain ring, S size: 170mm M size: 175mm L size: 175mm XL size: 175mm, CL 55 |
Chainring | 34T,CNC-machined alloy |
Bottom Bracket | SRAMDUBBSA, sealed bearings, 73mm |
Chain | Sram GX Eagle, 12s, Powerlock |
Rear Derrailleur | Sram X01 Eagle, Type 2.1 roller bearing clutch, cage lock, long carbon cage, 1×12s, X-actuation 1:1 |
Shifter | Sram GX Eagle, 12s |
Cassette | Sram XG-1275, 10-52T, 12s |
Max System Weight | 120kg – The maximum system weight is the maximum total weight of the bike, rider and any luggage combined |
