Frame
F-Play 24 6061 Alloy Stealth Evo, Hydroformed Tubing, Zero Suspension System, 120mm travel, Internal non-removable battery, Tapered head tube, HHG internal cable routing, BSA bottom bracket, QR 9mm rear axle, 1x drivetrain compatible
Shock
X-Fusion 02PRO R, 165x42.5mm / Settings: low-speed rebound, air preload / Trunnion top, 50x8mm bottom bushings
Fork
X-Fusion Velvet RL 26 Air, 120mm travel, tapered steerer, 15x100mm axle, 32mm aluminium stanchions, 41mm offset, lockout, rebound, air preload
Headset
Acros AZX-239 R1 Block Lock 135°, ZS44/28.6 top, ZS56/40 bottom
Crank
Samox DM, 152mm, 30T,
Shifters
SRAM trigger GX, 10 speed, X-actuation 1:1
Cassette
SRAM PG 1020, 11-36T, 10 speed
Rear derailleur
SRAM GX, 10 speed, short cage
Chain
SRAM PC1031, 10 speed, Powerlock
Handlebar
MDK XC 1.0, 6061 alloy, rise: 25mm, width: 680mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Stem
Onoff Sulfur FG, 30mm, 0º, 6061 forged alloy, 31.8mm barbore
Brakes
Sram Level, 2 piece caliper, Centerline 180mmF/160mmR IS 6 bolts one-piece rotor
Rims
MDK-HP1 24 TLR, 25mm internal width, tubeless ready, 32 spokes
Front Hub
DA210FS02, 15x100mm, IS 6 bolts
Rear Hub
Mahle-Ebikemotion X-35
Tyres
Kenda Regolith, 24x2.4", 120TPI, Folding, TLR
Seatpost
Onoff Pija dropper internal, diameter 31.6mm, 100mm
Saddle
SDG Fly JR
Grips
Onoff Twin, 1lock-on
Motor
Mahle-Ebikemotion X-35
Battery
Mahle-Ebikemotion Internal 250Wh
Display
Mahle-Ebikemotion
