Frame | e-Gravel Stealth Air Carbon, pressfit 386 EVO bottom bracket, tapered head tube, HHG internal cable routing, integrated internal non-removable battery, 12×142mm rear axle, 1X or 2X drivetrain design, Flatmount brake compatible, integrated dropout speed sensor |
Fork | Steatlh Air Carbon tapered steerer tube, HHG, fllat mount integrated fork |
Headset | OnOff e-gravel tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41×30.2×7×45°x45°, bottom 51.9×40×8×45°x45° |
Stem | Mondraker e-gravel 6061 T6 Alloy, 31.8mm barbore, rise: +/-7°, length: sizes S/M: 70mm, size L: 80mm XL: 90mm |
Handlebar | OnOff Barium gravel 18° bar flare. Width sizes S/M: 440mm, size L/XL: 460mm |
Bartape | Barium gravel dark grey |
Seatpost | OnOff Barium gravel carbon microadjust diameter 27.2mm, length 400mm |
Saddle | Selle Royal Prestige 139mm |
Front Brake | SRAM Apex 1, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad |
Rear Brake | SRAM Apex 1, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad |
Rims | MDK-XG1, 23mm internal width, tubeless ready, 32 spokes |
Spokes | CN round stainless steel |
Front Hub | Novatec D041, Boost 12×100mm, sealed bearings, IS 6 bolts |
Rear Hub | Mahle X20 12×142mm, sealed bearings, IS 6 bolts |
Front Tyre | Maxxis Re-fuse 700×40, tubeless ready, dual compound, MaxxShield EXO protection, 60 TPI, folding bead, light tan wall |
Rear Tyre | Maxxis Re-fuse 700×40, tubeless ready, dual compound, MaxxShield EXO protection, 60 TPI, folding bead, light tan wall |
Crankset | SRAM Apex 1 Wide, S: 170mm, M: 172,5mm, L: 172,5mm, XL: 175mm |
Chainring | Sram X-Sync Eagle 40T direct mount, alloy, narrow-wide |
Bottom Bracket | Mahle DUB pressfit, sealed bearings |
Chain | Sram Apex, 12s, Powerlock |
Rear Derraileur | Sram Apex XPLR 12s |
Shifter | Sram Apex D1 12s, X-Actuation 1:1, single click |
Cassette | Sram PG-1231 11-44, 12s |
Motor | Mahle X20 Drive Unit |
Battery | Mahle X20 IX350Wh |
Display | Pulsar One Wireless |
Mudguards | Mondraker Dusty |
Max System Weight | 135kg – The maximum system weight is the maximum total weight of the bike, rider and any luggage combined |
