Frame
Aluminum Superlite, Gravity Casting Technology, Efficient Comfort Control, FSP 4-Link, Agile Comfort Geometry, Boost 148, Fully Integrated Battery, Advanced Internal Cable Routing, Kickstand/Fender/Carrier Mounting Points
Size
Size Split: 27.5: S // 29: M L XL
Suspension Fork
Fox 34 Float AWL, 2-Position Sweep-Adjust RAIL Damper, Tapered, 15x110mm, E-Bike Optimized, 120mm
Shock
Fox Float DPS EVOL, 185x55mm (27.5: 165x45mm), Open/Medium/Firm Mode, Trunnion Mount
Shock Hardware
Top: 54mm Trunnion Mount, Bottom: 30x8mm
Drive Unit
Bosch Drive Unit Performance CX Generation 4 (85Nm) Cruise (250Watt), Smart System
Remote
Bosch LED Remote
Battery
Bosch PowerTube 750
Display
Bosch Intuvia 100
Charger
Bosch 4A
Brake System
Magura MT Thirty, Front 4-Piston/Rear 4-Piston, Hydr. Disc Brake (203/203)
Rear Derailleur
Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed
Shifters
Shimano Deore SL-M6100, Rapidfire-Plus
Crankset
ACID E-Crank, 38T, 170mm
Cassette
Shimano Deore CS-M6100, 10-51T
Chain
Shimano CN-M6100
Headset
ACROS AZF-1035, ICR (Integrated Cable Routing), BlockLock 120°, Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm)
Stem
CUBE Performance Stem E-MTB, 31.8mm
Handlebar
Newmen Evolution SL 318.25, 760mm
Grips
ACID Hybrid Perform
Rims
CUBE EX30, 32H, Disc, Tubeless Ready
Front Hub
Shimano HB-MT400-B, 15mm, Boost, Centerlock
Rear Hub
Shimano FH-MT410-B, 12mm, Boost, Centerlock
Tyres
Schwalbe Smart Sam, Active, 2.6
Saddle
Natural Fit Sequence
Seat Post
CUBE Performance Post, 30.9mm
Pedals
ACID PP MTB
Weight
25,6 kg
